Рамы

Рекомендованная максимальная длина рамы

Профили	Максимальная длина рамы при натяжении
	прим. 12 N/cm	прим. 15 N/cm	прим. 20 N/cm	прим. 25 N/cm	прим. 30 N/cm
30 x 30 x 3,0/1,8 mm	70 cm	64 cm	57 cm	51 cm	42 cm
38,1 x 25,4 x 2,5 mm	80 cm	74 cm	66 cm	58 cm	49 cm
35 x 35 x 2,5 mm	80 cm	74 cm	66 cm	58 cm	49 cm
SLOPE 40/30 x 30 x 3,0/1,8 mm	85 cm	78 cm	70 cm	62 cm	52 cm
40 x 30 x 2,5 mm	90 cm	83 cm	74 cm	66 cm	55 cm
38,1 x 38,1 x 2,8/2,0 mm	109 cm	100 cm	89 cm	80 cm	66 cm
40 x 40 x 2,8/2,0 mm	120 cm	110 cm	98 cm	88 cm	73 cm
SLOPE 45/35 x 40 x 3,1/1,8 mm	130 cm	120 cm	107 cm	95 cm	80 cm
40 x 40 x 4,5/2,0 mm	150 cm	138 cm	123 cm	110 cm	90 cm
SLOPE 50/40 x 38 x 3,2/2,0 mm	160 cm	148 cm	132 cm	118 cm	98 cm
50 x 30 x 4,5/2,0 mm	176 cm	160 cm	144 cm	128 cm	108 cm
50 x 40 x 3,2/2,0 mm	180 cm	166 cm	146 cm	132 cm	110 cm
SLOPE 55/45 x 40 x 3,2/2,0 mm	190 cm	174 cm	155 cm	138 cm	116 cm
50 x 40 x 4,5/2,0 mm	210 cm	192 cm	172 cm	152 cm	128 cm
60 x 40 x 3,0/2,0 mm	225 cm	208 cm	184 cm	164 cm	138 cm
SLOPE 65/55 x 40 x 4,5/2,5 mm	260 cm	240 cm	212 cm	190 cm	159 cm
60 x 40 x 6,0/3,0 mm	275 cm	254 cm	225 cm	200 cm	168 cm
SLOPE 75/65 x 50 x 5,0/2,8 mm	315 cm	290 cm	258 cm	230 cm	192 cm
80 x 40 x 6,0/3,0 mm	340 cm	312 cm	280 cm	250 cm	208 cm
SLOPE 85/75 x 50 x 5,0/2,8 mm	350 cm	322 cm	288 cm	256 cm	214 cm
SLOPE 90/80 x 40 x 6,0/3,0 mm	360 cm	332 cm	296 cm	264 cm	220 cm
100 x 40 x 6,0/3,0 mm	420 cm	386 cm	345 cm	310 cm	256 cm
SLOPE 105/95 x 50 x 5,0/2,5 mm	420 cm	386 cm	345 cm	310 cm	256 cm
SLOPE 110/100 x 40 x 6,0/3,0 mm	440 cm	405 cm	360 cm	320 cm	270 cm
SLOPE 135/125 x 50 x 5,0/2,5 mm	600 cm	550 cm
SLOPE 160/150 x 50 x 5,0/2,5 mm	700 cm	640 cm
